Mitsubishi 17.5inch AA175TA03 LCD Panel

Place of Origin : Japan

Brand Name : Mitsubishi

Certification : RoHS Compliant

Model Number : AA175TA03

MOQ : 1 Pcs

Price : Pls Contact sales team

Packaging Details : MODULE

Delivery Time : stock

Payment Terms : T/T , Paypal, Western Union ,Escrow etc.

Supply Ability : 1000

Panel Model : AA175TA03

Panel Brand : Mitsubishi

Descrition : a-Si TFT-LCD ,17.5 inch, 1280×768

Panel Type : a-Si TFT-LCD

Contact Now

Mitsubishi 17.5inch AA175TA03 LCD Panel

Specification for AA175TA03:

AA175TA03 Basic Information

Panel Model

AA175TA03

Panel Brand

Mitsubishi

Descrition

a-Si TFT-LCD ,17.5 inch, 1280×768

Panel Type

a-Si TFT-LCD

Operating Temperature

0 ~ 50 °C

Storage Temperature

-20 ~ 60 °C

AA175TA03 Mechanical Features

Dot Resolution

1280(RGB)×768 (WXGA)

Pixel Configuration

RGB Vertical Stripe

Pixel Density

85 PPI

Aspect Ratio

15:9 (H:V)

Form Factor

Flat Rectangle Display

Dot Pitch

0.099×0.292 mm (H×V)

Pixel Pitch

0.297×0.292 mm (H×V)

Weight

1.70Kgs

Surface

Antiglare, Hard coating (3H)

Active Area

380.2×228.1 mm (H×V)

Bezel Area

384.2×232.1 mm (H×V)

Outline Dimension

404×258 mm (H×V)

Outline Depth

16.2 mm

Holes & Brackets

Side mounting holes (4-M3)

Landscape or Portrait

Landscape type

Touch Panel

Without

AA175TA03 Optical Features

Display Mode

TN, Normally White, Transmissive

Brightness

400 cd/m² (Typ.)

Contrast Ratio

500 : 1 (Typ.) (Transmissive)

Display Color

16.7M (8-bit)

Color Gamut

70% NTSC (CIE1931)

Response Time

6/19 (Typ.)(Tr/Td); 10 (Typ.)(Tr+Td)

Viewing Angle

75/75/60/50 (Typ.)(CR≥10) (L/R/U/D)

Viewing Direction

6 o'clock

White color Chromaticity

Wx:0.313; Wy:0.329

White Variation

1.30 (Max.)(5 points)

Sunlight Readable

N

AA175TA03 Electronics Feature

Vertical Frequency

60Hz

Reverse Scan

No

AA175TA03 Backlight System

Lamp Position

Edge light type (Top and Bottom)

Lamp Type

CCFL

Lamp Amount

4 pcs

Lamp Shape

Straight

Lamp Life Time

35K(Typ.) (Hours)

Lamp Voltage

750V (Typ.)

Lamp Current

5.0/7.0/8.0mA (Min./Typ./Max.)

Lamp Operating Frequency

40/70KHz (Min./Max.)

Lamp Startup Voltage

1500/1700V (Min.)(Ta=+25/0℃)

Interface Type

Connector

Lamp Driver Board

No

AA175TA03 Signal Interface

Signal Category

LVDS

Signal Class

LVDS (1 ch, 8-bit)

Input Voltage for Panel

5.0V (Typ.)

Input Current for Panel

450/960mA (Typ./Max.)

Interface Type

Connector

Signal Interface

HRS - DF14H-20P-1.25H, Pitch:1.25 mm, Pin:20 pins
